Spencer laboratory compound microscope
Datecirca 1916
Inventory Number1997-1-1894
ClassificationMicroscope
Subject
Maker
Spencer Lens Company
1895 - 1945
Inventor
Ernst Abbe
1840 - 1905
Cultural Region
Place of Use
Dimensionsmicroscope: 30 × 11 × 17.5 cm (11 13/16 × 4 5/16 × 6 7/8 in.)
case: 40.5 × 18.5 × 21.5 cm (15 15/16 × 7 5/16 × 8 7/16 in.)
case: 40.5 × 18.5 × 21.5 cm (15 15/16 × 7 5/16 × 8 7/16 in.)
Material
AccessoriesSpencer objectives with canisters (3): 1.8, 4, 16 mm; anonymous oculars (3): 10x, 1, 3; Abbe condenser; substage mirror; standing case; key; blue filter
DescriptionThis is a Spencer compound laboratory microscope. It has a blackened horseshoe shaped base of cast iron, a monocular body tube with a draw tube that is graduated in millimeters. The arm has the handle built in. There is a revolving triple nosepiece. The coarse adjustment is by rack and pinion. The fine focus is by a graduated knob on top of the post that works on an internal lever. Both the fine and coarse adjustment knobs are red brass as is a strip on the arm.
There is a square stage with nickel stage clips. Beneath the stage is an Abbe condenser with iris diaphragm and ring for filters. It is moved up and down by means of a large vertical screw on the proper left. The mirror is on a swinging arm.
This instrument is accompanied by a standing wooden case with a key.
There is a square stage with nickel stage clips. Beneath the stage is an Abbe condenser with iris diaphragm and ring for filters. It is moved up and down by means of a large vertical screw on the proper left. The mirror is on a swinging arm.
This instrument is accompanied by a standing wooden case with a key.
Signedon foot: SPENCER LENS CO. / Buffalo, N.Y.
on key: S / L
Inscribedon foot: 33449
on foot: Betz
ProvenanceGift of Mrs. Lillian T. Green in memory of her husband, Dr. William T. Green, 1992.
