Wheatstone's photometer
Wheatstone's photometer

Wheatstone's photometer

Date1850-1890
Inventory Number2001-1-0031
ClassificationPhotometer
Subject
    Maker French ?
    Cultural Region
      Dimensions3.7 × 4.9 × 4.9 cm (1 7/16 × 1 15/16 × 1 15/16 in.)
      Material
        DescriptionWheatstone's photometer consisting of a small circular brass drum with a brass and steel crank fitted into the base. The crank turns an off-centered steel disk which is then rotated by the rim of gear teeth at the edge. The steel disk has 14 sharp pins on its surface, to which may be attached cork discs containing steel beads (the latter missing here).
        Signedunsigned
        FunctionFor comparing the brightness of two light sources. It provides an approximation, not a hard quantitative, measurement.

        For more information, see the explanation in Ganot's treatise on physics at the following website.
        Historical AttributesFor references see: Turner, Gerard L'E. "The Practice of Science in the 19th Century." The Teyler's Museum (1996), pp. 185-186; Atkinson, trans. "Ganot's Physics." London (1867), pp. 375-376; Brenni, Paolo. "Gli strumenti di fisica dell'Instituto Tecnico Toscano." Florence (1995), pp. 68-69.
