surveyor's compass
Datecirca 1850
Inventory Number5203a
ClassificationSurveyor's Compass
Subject
Maker
E. & G. W. Blunt
1824 - 1866
Cultural Region
Place of Origin
Dimensions20.3 x 36.2 x 16.5 cm (8 x 14 1/4 x 6 1/2 in.)
blue board box: 23.5 × 39.4 × 20.6 cm (9 1/4 × 15 1/2 × 8 1/8 in.)
blue board box: 23.5 × 39.4 × 20.6 cm (9 1/4 × 15 1/2 × 8 1/8 in.)
Material
Accessoriesball-and-socket joint (5203b); tripod (5203c)
DescriptionThe instrument is made of brass with a silver dial. The two sighting vanes are removable. One is made of two narrow slits, the other of eight small circular apertures (four for the upper and four for the lower slits when looking through the latter). There is a small thumb knob to adjust the lifter arm.
On the South side, on the arm, is a circular universal bubble level. On the North side, an unusual round counter (0-10). The dial's face only has eight cardinal points. Degrees are engraved on the raised divided scale (0-360), divided in half degrees and marked to every ten. It is supported by a heavy ball-and-socket joint and a tripod.
On the South side, on the arm, is a circular universal bubble level. On the North side, an unusual round counter (0-10). The dial's face only has eight cardinal points. Degrees are engraved on the raised divided scale (0-360), divided in half degrees and marked to every ten. It is supported by a heavy ball-and-socket joint and a tripod.
Signedon arm, counter: E & G W Blunt / New York
FunctionThe surveyor's compass is an instrument used in surveying (or in navigation in rare cases) to measure horizontal angles, what is called bearing or azimuth.
For a nice discussion of this intrument, see the following website.
For a nice discussion of this intrument, see the following website.
ProvenanceAlexander Johnston, Jr. (1815-1890), Wiscasset, Maine; David Wheatland acquired from Nelson J. Sanford, Damariscotta, Maine, July 30, 1970. Donated to CHSI February 2, 1977.
