Casting pattern: Pendulum top block or dial foot
Date19th Century
Inventory Number2005-1-0106
ClassificationCasting Pattern
Subject
Maker
William Bond and Son
fl. 1793 - 1977
Associate Name
Alvan Clark and Sons
1846 - 1958
Cultural Region
Place of Origin
DimensionsStorage box: 7 x 7 x 4 cm (stored in same box as 2005-1-0108)
Material
DescriptionWood casting pattern for what is either a pendulum top block or a dial foot for a regulator. The original Bond Pattern Inventory (1988) states: "Pendulum top block(?) or reg. dial foot (1) (Alvan Clark type).
Signedunsigned
FunctionBefore sand casting an instrument part from brass or other metal, a foundry pattern is made from wood or metal. The pattern is a replica of the part to be cast,. The pattern is pressed into sand, creating a cavity into which the molten metal will be poured.
ProvenanceWilliam B. Osgood, gift to CHSI, 1959.
Historical AttributesThese foundry patterns came from the workshop of William Bond & Son. Some of the patterns are associated with astronomical regulators and instruments used at the Harvard College Observatory. These instrument are currently in the Harvard Collection of Historical Scientific Instruments.
