Casting pattern for a part for Bond Regulators No. 394, 395 & 396
Casting pattern for a part for Bond Regulators No. 394, 395 & 396

Casting pattern for a part for Bond Regulators No. 394, 395 & 396

Datecirca 1867
Inventory Number2005-1-0132
ClassificationCasting Pattern
Subject
    Maker William Bond and Son fl. 1793 - 1977
    Cultural Region
      Place of Origin
        Material
          DescriptionT-shaped wood casting pattern for a part for several different Bond Regulators (394, 395, & 396).
          Signedunsigned
          InscribedIn red paint: III
          FunctionBefore sand casting an instrument part from brass or other metal, a foundry pattern is made from wood or metal. The pattern is a replica of the part to be cast,. The pattern is pressed into sand, creating a cavity into which the molten metal will be poured.
          ProvenanceWilliam B. Osgood, gift to CHSI, 1959.
          Historical AttributesThese foundry patterns came from the workshop of William Bond & Son. Some of the patterns are associated with astronomical regulators and instruments used at the Harvard College Observatory. These instrument are currently in the Harvard Collection of Historical Scientific Instruments.
