flame testing apparatus
Date1870-1930
Inventory Number1998-1-1593
ClassificationBurner
Subject
Maker
American
?
Cultural Region
Dimensions49 x 20.5 x 13 cm (19 5/16 x 8 1/16 x 5 1/8 in.)
Material
DescriptionTwo identical steel tubes with nozzles at their bottom and a metal disk a few inches above the nozzle, placed vertically with black metal casings from which they hang attached above them. They are attached next to each other to stand with a rectangular base and a straight vertical tube
One casing is cylindrical slightly decreasing in diameter. It has a paddle with holes of three different diameters atop it that one can place over its mouth. The other casing is a cylinder increasing in diameter but with its top edge collapsed and welded together to present a semi-circular sharp edge. It has several round holes at its bottom near where the nozzle emerges from it.
One casing is cylindrical slightly decreasing in diameter. It has a paddle with holes of three different diameters atop it that one can place over its mouth. The other casing is a cylinder increasing in diameter but with its top edge collapsed and welded together to present a semi-circular sharp edge. It has several round holes at its bottom near where the nozzle emerges from it.
Signedunsigned
