Beck binocular compound microscope
Datecirca 1885
Inventory Number1273
ClassificationMicroscope
Subject
Maker
R. & J. Beck
1865 - 1920
Cultural Region
Place of Origin
Dimensions36 × 14.7 × 27.5 cm (14 3/16 × 5 13/16 × 10 13/16 in.)
Material
Accessoriesobjectives (3); paired oculars
DescriptionThis is a Beck binocular compound microscope. The heavy brass instrument sits on a flat tripod-shaped base. The binocular draw tubes are adjustable by rack and pinion in the body tubes. The binoculars are attached to a revolving triple nosepiece equipped with three objectives (only two of them are by R. & J. Beck). Fine adjustment is by a knob located on top of the arm.
There is a circular stage with an aperture and an ivory-tipped screw for the slide holder. Substage equipment includes a parabolic reflector, iris diaphragm, holder for stops, and a mirror on an adjustable arm.
There is a circular stage with an aperture and an ivory-tipped screw for the slide holder. Substage equipment includes a parabolic reflector, iris diaphragm, holder for stops, and a mirror on an adjustable arm.
Signedon revolving nosepiece: R. & J. Beck, LTD.
on base: R & J. BECK LONDON
Inscribedon objective: sold by Clarkson, London, WC1
on base: 12139
ProvenanceDavid Wheatland purchased from Roux-Devillas Paris, September 29, 1967 (lot 8/21). Donated to CHSI October 14, 1967.
