two-phase generator
Date1920-1950
Inventory Number0149a,b
ClassificationGenerator
Subject
Maker
Spindler & Hoyer
1898 - 1996
User
Department of Physics, Harvard University
founded 1884
Cultural Region
Place of Origin
Dimensions11.5 × 35 × 9 cm (4 1/2 × 13 3/4 × 3 9/16 in.)
Material
Bibliography
DescriptionThis generator consists of a horse-shoe permanent magnet fixed on a cast iron base. Within the magnet's field are two coils wound on iron cores, set at a 90-degree angle. The coils are mounted on a horizontal shaft, each coil being linked to collecting rings and collector springs. The wheel turning the shaft has a handle so it can be rotated by hand. The wheel though is grooved, to act as a pulley, so it can also be mechanically turned by a motor.
Signedon instrument: SPINDLER & HOYER / GÖTTINGEN
FunctionThis device was used to generate AC current by a fluctuating magnetic field. Note that the total sum of AC current produced by this system is zero at all time.
For an example on how a three-phase generator works, go to the following website.
For an example on how a three-phase generator works, go to the following website.
ProvenanceFrom the Department of Physics, Harvard University.
