Barth's feed-speed slide rule
Datepatented 1904
Inventory Number1990-3-0003
ClassificationSlide Rule
Subject
Maker
Carl G. Barth
1860-1939
Associate Name
Frederick W. Taylor
1856-1915
Cultural Region
Place of Origin
Dimensions2.5 x 20.8 x 12.8 cm (1 x 8 3/16 x 5 1/16 in.)
Material
DescriptionRectangular rule with seven slides, faced with off-white paper. The top, fourth, and bottom slides are fixed; the second, third, fifth, and sixth slides move to left and right.
Printed along the bottom edge of the top slide is a scale for "CLASS NO.," with values (in whole numbers) ranging from 0 to 30.
On the left-hand side of the second, moveable slide is a grid for "BELT DATA. / VELOCITY IN THOUSAND FEET / AND CROSS-SECTION IN SQ. INS." The grid's off-vertical lines are labeled with values ranging from 0.2 to 2.5; its horizontal lines are labeled with values 1, 2, 3, and 4.
The bottom edge of the right-hand side of the same (second) slide is printed with a scale for "DEPTH OF CUT," with values ranging from 3/32'' to 1''.
The top edge of the third, moveable slide is printed with a scale for "DIAMETER OF WORK," with values descending from 60'' to 2''. Near the bottom edge of the same slide is a scale for "CONE DIAM. X GEAR REDUCTION," with values descending from 3000'' to 3''.
Near the top and bottom edges of the fourth slide is a scale for "FEED," with values descending from 0.4 to 0.0005.
Printed near the top edge of the fifth, moveable slide is a scale for "REV. OF SPINDLE," carrying values from 2 to 200. The bottom edge of the same slide is printed with a scale for "DIAMETER OF WORK," with values descending from 60'' to 2''.
Along the top edge of the sixth, moveable slide is a scale for "CLASS NO.," with values (in whole numbers) ranging from 0 to 30. The bottom edge of the same slide is printed with three scales for "DEPTH OF CUT." The left-most scale, labeled for a "1 1/4'' TOOL," has values descending from 1'' to 3/32''. The center scale, labeled for a "3/4'' TOOL," has values descending from 3/4'' to 3/32''. The right-most scale, labeled for a "1/2'' TOOL," has values descending from 1/2'' to 3/32''.
Printed along the top edge of the bottom slide are three identical scales for "LIFE OF TOOL," each with values ranging from 10MIN. to 2HRS.
Printed along the bottom edge of the top slide is a scale for "CLASS NO.," with values (in whole numbers) ranging from 0 to 30.
On the left-hand side of the second, moveable slide is a grid for "BELT DATA. / VELOCITY IN THOUSAND FEET / AND CROSS-SECTION IN SQ. INS." The grid's off-vertical lines are labeled with values ranging from 0.2 to 2.5; its horizontal lines are labeled with values 1, 2, 3, and 4.
The bottom edge of the right-hand side of the same (second) slide is printed with a scale for "DEPTH OF CUT," with values ranging from 3/32'' to 1''.
The top edge of the third, moveable slide is printed with a scale for "DIAMETER OF WORK," with values descending from 60'' to 2''. Near the bottom edge of the same slide is a scale for "CONE DIAM. X GEAR REDUCTION," with values descending from 3000'' to 3''.
Near the top and bottom edges of the fourth slide is a scale for "FEED," with values descending from 0.4 to 0.0005.
Printed near the top edge of the fifth, moveable slide is a scale for "REV. OF SPINDLE," carrying values from 2 to 200. The bottom edge of the same slide is printed with a scale for "DIAMETER OF WORK," with values descending from 60'' to 2''.
Along the top edge of the sixth, moveable slide is a scale for "CLASS NO.," with values (in whole numbers) ranging from 0 to 30. The bottom edge of the same slide is printed with three scales for "DEPTH OF CUT." The left-most scale, labeled for a "1 1/4'' TOOL," has values descending from 1'' to 3/32''. The center scale, labeled for a "3/4'' TOOL," has values descending from 3/4'' to 3/32''. The right-most scale, labeled for a "1/2'' TOOL," has values descending from 1/2'' to 3/32''.
Printed along the top edge of the bottom slide are three identical scales for "LIFE OF TOOL," each with values ranging from 10MIN. to 2HRS.
Signedface, third slide on right: CAST IRON / Carl G. Barth
Inscribedface, top slide on right: PATENTED MARCH 8TH, 1904.
Curatorial Remarks\Identical in function to 1990-4-0099, though the latter is for making calculations when cutting steel, while this instrument is making calculations when cast iron. In addition, this instrument has a "CLASS NO." scale instead of an arrow on the top slide, is of different dimensions, and is raised on wooden legs.;
Similar in function to Italian-language feed-speed rule, see 1990-4-0002;
Similar in function to 1990-4-0038, though with some variables different.
FunctionFor calculating the most efficient feed-speed setting combination when cutting cast iron on a lathe or similar machine.
The user first moves the second slide to left or right until the point on the grid (second slide) representing the appropriate belt cross-section and velocity aligns with the appropriate value on the class number scale (top slide). Holding the second slide in place, he then moves the third slide to left or right such that the appropriate value on the diameter of work scale (third slide) coincides with the appropriate value on the depth scale (second slide).
Holding the second and third slides in place, the user then moves the sixth slide to left or right until the appropriate value on the depth of cut scale matching his tool size (sixth slide) aligns with the length of time he needs to use the tool on the adjacent life of tool scale (bottom slide). Finally, holding the second, third, and sixth slides in place, the user moves the fifth slide to left or right such that the appropriate value on the diameter of work scale (fifth slide) coincides with the appropriate value on the class number scale (sixth slide).
Only those values for spindle revolutions (fifth slide) and cone diameter (third slide, adjusted, as needed, according to whether or not back gears are in use) that fall within the feed scale (fourth slide) will maximize efficiency. Thus, the user should, in choosing among the feed and speed settings available on his particular machine, select that combination whose values on the third, fourth, and fifth slides come closest to coinciding.
The user first moves the second slide to left or right until the point on the grid (second slide) representing the appropriate belt cross-section and velocity aligns with the appropriate value on the class number scale (top slide). Holding the second slide in place, he then moves the third slide to left or right such that the appropriate value on the diameter of work scale (third slide) coincides with the appropriate value on the depth scale (second slide).
Holding the second and third slides in place, the user then moves the sixth slide to left or right until the appropriate value on the depth of cut scale matching his tool size (sixth slide) aligns with the length of time he needs to use the tool on the adjacent life of tool scale (bottom slide). Finally, holding the second, third, and sixth slides in place, the user moves the fifth slide to left or right such that the appropriate value on the diameter of work scale (fifth slide) coincides with the appropriate value on the class number scale (sixth slide).
Only those values for spindle revolutions (fifth slide) and cone diameter (third slide, adjusted, as needed, according to whether or not back gears are in use) that fall within the feed scale (fourth slide) will maximize efficiency. Thus, the user should, in choosing among the feed and speed settings available on his particular machine, select that combination whose values on the third, fourth, and fifth slides come closest to coinciding.
ProvenanceThe papers and slide rules of Carl G. Barth and his son, J. Christian Barth, were transferred to the Baker Library of the Harvard Business School by J. Christian Barth in 1961.
The slide rules were transferred from Harvard Business School to the Collection of Historical Instruments in 1980.
Historical AttributesThis is part of a set of slide rules for machine shops designed by Carl G. Barth under Frederick Winslow Taylor's system of scientific management. Given the characteristics of a particular machine and a depth of cut, for example, a shop manager could quickly calculate the most efficient speed and feed settings using one of Barth's speed and feed slide rules. Other objects in the collection include slide rules for helical springs, belts, and gears, as well as jigs for making slide rules.
